Description
The MasterFrame 600 is a premium open-frame mid-tower chassis built for high-performance hardware, extreme cooling, and total customization.
Designed with Freeform 2.0 in mind, it supports ATX to E-ATX motherboards and offers full access to modular design files, empowering users to build and evolve without limits.
FreeForm 2.0 Exo-structure
The exposed frame structure enhances chassis adaptability and provides flexible configuration options for various scenarios.
Flexible Motherboard Support
Supports Mini-ITX to E-ATX motherboards, offering compatibility with a wide range of builds and configurations.
Versatile & Maker-Driven
Its open-source design and interchangeable panels offer endless personalization possibilities, transforming your chassis into a unique expression of style.
Extensive Cooling Support
Can house up to eleven fans and multiple radiator sizes (up to 420mm), ensuring superior thermal performance.
Ample GPU Clearance
Accommodates graphics cards up to 485mm, offering plenty of space for high -end GPUs.
Included GPU support bracket
The included GPU support bracket prevents GPU sag and ensures stability during intense gaming or high – performance workloads, maintaining a clean and secure build.
Description
Specification
- Form Factor: ATX
- #Hide#Small Form Factor: No
- Power Supply Wattage: No PSU
- Motherboard Support: “Mini-ITX, Mini-DTX, Micro-ATX, ATX , E-ATX*, SSI-CEB* (*Conditional Support)”
- #Hide#Window(s): Yes (Window)
- #Hide#LED Lighting: Yes (LED Lighting)
- Connectors / Controls: 1 x USB 3.2 Gen 2×2 Type C
2 x USB 3.2 Gen 1 Type A
1 x 3.5mm Headset Jack (Audio+Mic) - Drive Bays: 2 x 2.5″” / 3.5″” Drive Bays (Combo)
3 x 2.5″” Drive Bays - Expansion Slots: 8 Expansion Slots
- Cooling System: Included:
Front: 3 x SickleFlow ARGB 140mm Fans
Rear: 1 x SickleFlow ARGB 120mm FanFan Mounts:
Front: 3 x 120 / 3 x 140 / 2 x 180 / 2 x 200 mm
Top: 3 x 120 / 2 x 140 / 2 x 180 / 1x 200 mm
Rear: 1 x 120 mm
Side: 3 x 120 / 3 x 140 mm - .:
Radiator Options:
Front: Up to 420 mm (Limit: 458 mm)
Top: 120 / 140 / 240 / 280 / 360 / 420* mm
Rear: 120 mm
Side: Up to 420 mm*Up to 420mm if I/O module is moved to the front panel
- Colour: Black
- Material: “Exterior: SGCC Steel, Aluminium
Side Panel (Right / Left): Tempered Glass / Aluminium” - Compatibility: GPU Clearance:
L: 485 mm (incl. power connector)
H: 190 mm (incl. power connector)CPU Clearance:
190 mmPSU Clearance:
235 mmCable Routing (Behind MB Tray):
43 mm - Weight/Dimensions: (LxWxH) 531 x 261 x 544 mm (Incl. Protrusions)
(LxWxH) 514 x 244 x 514 mm (Excl. Protrusions)
Volume (incl. Protrusions): 73.6L - Additional Features: “FreeForm 2.0 Exo-Structure for Flexible Configuration Options
GPU Support Bracket included
Dust Filters: Top, Front, Bottom, Right Side Panel
Tool-Free Panel RemovalSee Overview for more details”
- Package Weight: 15.2000 kg
- Warranty: 2 Years
